Product Description
Standard Feature- Modular, solid state circuitry
- Proprietary DC motor drive system
- Microprocessor-controlled, infinitely variable backgauge drive
- Repeatability of backgauge position to +/-.002 inches (.05 mm)
- Automatic backgauge return
- Measurements in inches, centimeters, millimeters or sun
- Program entry or correction, through the keyboard with the backgauge stationary or while cutting the lift
- Automatic computation and entry of fractions
- Insertion or deletion of commands from existing programs
- Stock eject, turnaround, loading points and job information
- Infinite lay compensate mode for as many sides as requested
- Non-volatile memory - no batteries required for memory support
- Optional auxiliary controls for air and/or brake
- Minimum trim cut: .002 inch (.05 mm)
- Speed range: 24 - 960 inches per minute, both forward and reverse, depending on size and condition of cutter
- Self-diagnostic electronics
- Electrical: 85 - 265 VAC, 50/60 Hz @ 1 KVA
