Product Description
Lauda Ultracool Circulation Chiller UC-0240SP
Ultracool UC-0240 SP
Working temperature min.: -5 °C
Working temperature max. 25 °C
Ambient temperature min. -15 °C
Ambient temperature max. 50 °C
Temperature stability 2 ±K
Cooling output at 25°C water outlet temperature 37.3 kW
Cooling output at 20°C water outlet temperature 34.6 kW
Cooling output at 15°C water outlet temperature 30.3 kW
Cooling output at 10°C water outlet temperature 26.3 kW
Cooling output at 5°C water outlet temperature 22.3 kW
Cooling output at 0°C water outlet temperature 18.2 kW
Cooling output at -5°C water outlet temperature 14.5 kW
Number of refrigeration circuits 1
Application external
Power consumption 8 kW
Pump pressure max. 4.2 bar
Pump pressure nominal 2.7 bar
Pump flow max. (pressure) 130 L/min
Pump flow nominal 84 L/min
Pump connection thread HT DN25
Volume water reservoir 100 L
Dimensions (WxDxH) in mm 715x945x1490
Noise level 57.5 dB(A)
Max. fuse 40 A
